ASUS RTX 3080 EKWB

RTX 30 · RTX 3080 EKWB · RTX 3080
ASUS RTX 3080 EKWB product image
ASUS RTX 3080 EKWB product image 1ASUS RTX 3080 EKWB product image 2ASUS RTX 3080 EKWB product image 3ASUS RTX 3080 EKWB product image 4

General

SeriesRTX 30
ModelRTX 3080 EKWB
ChipRTX 3080
Launch Year2020
Release Date9/17/2020
Launch MSRP$699
Is this part compatible with your build?Analyze part compatibility together with PC Analysis.
Analyze in PC Builder

Architecture

ArchitectureAmpere
GPU DieGA102 (GA102-200-KD-A1 / GA102-202-KD-A1)
FoundrySamsung · 8 nm
Transistors28.3 billion
Die Size628 mm²

Cores

Shading Units8704
TMUs272
ROPs96
SM / CU68
Tensor Cores272
RT Cores68
L2 Cache5 MB

Memory

VRAM10 GB
Memory TypeGDDR6X
Memory Bus320-bit
Memory Speed19 Gbps

Clocks and Power

Base Clock1440 MHz
Boost Clock1710 MHz
TDP320 W
Power Connector8-pin
Recommended PSU700 W

Compute (TFLOPS)

FP3229.77 TFLOPS
FP1629.77 TFLOPS
FP640.47 TFLOPS

Display Outputs

HDMI1×
DisplayPort3×

Cooling

Fan Count0
Liquid Cooling✓ Yes

Physical

Length216 mm
Width20 mm
Height136 mm
Slot Width1 slot

Interface

PCIe Version4.0
PCIe Lanesx16

Software and Technologies

API Support
DirectX 12 Ultimate (12_2)
CUDA 8.6
Vulkan 1.4
OpenCL 3.0
OpenGL 4.6
Shader Model 6.9
Hardware Encoder
1x NVENC (7th Gen, max. Sessions: 8)
1x NVDEC (5th Gen)
Encoding
H.265 (4K YUV 4:2:0 / 4K YUV 4:4:4 / 4K Lossless / 8K / HEVC 10bit support / HEVC B Frame support)
H.264 (YUV 4:2:0 / YUV 4:4:4 / Lossless)
Decoding
AV1 (8bit / 10bit)
H.265 (8bit 4:2:0 / 10bit 4:2:0 / 12bit 4:2:0 / 8bit 4:4:4 / 10bit 4:4:4 / 12bit 4:4:4)
H.264 (8bit 4:2:0)
VP9 (8bit / 10bit / 12bit)
VP8
VC-1
MPEG-2
MPEG-1
